Rock Exotica Aztek P41 Pulley Kit
The AZTEK system has become the ultimate Personal Mechanical Advantage kit that can be configured as a 5:1, or 4:1 with a re-direct by just rotating the system. The AZTEK can be used as a pick off, adjustable directional, high directional guyline, high angle attendant tether, high angle litter scoop, load release hitch and much more. Each pulley is color coded to match with a corresponding prusik for quick identification. The AZTEK pulleys are machined from solid aluminum, feature swivel connection points, and utilize high efficiency bearings.
The AZTEK KIT includes
- 1 x Rock Exotica Omni AZTEK Elite blue pulley
- 1 x Rock Exotica Omni AZTEK Elite orange pulley
- 1 x Sterling AZTEK orange ratchet
- 1 x Sterling AZTEK blue ratchet
- 1 x 8mm Sterling Rope, 50 feet long
- 1 x standard leg bag
PMA Configuration: 5:1 or 4:1
Standards: CE 0120, EN12278 & EN795
Strength:
- 36kN with top Prusik
- 30kN with bottom Prusik
- 18kN when tested only on one sheave, no Prusik.
Part#: P41 AZTEK PULLEYS
2 x Aztek Double Pulleys
1 x Quick Release Prusik Pin
1 x Rope Cover
Sheave diameter: 1 inch (25 mm)
Sheave: Double
Sheave material: Aluminum
Weight: 15.4 ounces (436gms)
Breaking strength (Each Pulley): 2 x 9 kN x 2 = 36 kN
Working load human load: 3 kN
Working load: 5 kN non live load
Maximun rope diameter: 5/16" (8mm)
Certification: CE
Aztek Technical Notice Click Here
Declaration of Conformity Click Here
Manufactured in USA
