SLEEVE STL/STL DUPLEX 1/2"
STAINLESS 1-PC DUPLEX SLEEVE
1/2 inch Upson-Walton One-Piece Stainless Steel Duplex Sleeve
After swage diameter
Minimum: 0.97 inches
Nominal: 1.00 inches
Maximum: 1.05 inches
***One-Piece Stainless Steel Duplex Sleeves are recommended for use on 6 x 19 or 6 x 37 IPS or XIP, EIP, RRL, or IWRC wire rope. It is
recommended that a test assembly be destructively tested to prove the adequacy of the assembly.
Made in USA
